ZigBee is a specification based on the IEEE 802.15.4 standard for Wireless Personal Area Networks (WPANs). ZigBee operates in the ISM radio bands and is an open, global, and inexpensive network for industrial control, embedded sensing, data collection, smoke and intruder alarms, building automation, and home automation.
VIDEO
ZigBee AIO (Router)
Wireless 8-ch Thermistor Input Module
Wireless 6-channel RTD Input Module
RTD Pt100, Pt1000, Ni120, Cu100, Cu1000
Wireless 8-channel Analog Input Module
±10V, ±5V, ±1V, ±500mV, ±150mV, ±20mA, 0 ~ 20mA, ±20mA, 0 ~ 20mA or 4 ~ 20mA (Current Input Requires Optional External 125 Ω Resistor)
Wireless 8-channel Current Input Module
-20mA ~ +20mA, 0mA ~ +20mA or +4mA ~ +20mA
Wireless 8-channel Current Input Module
±15 mV, ±50 mV, ±100 mV, ±500 mV, ±1V, ±2.5V, ±20mA, 0 ~ 20mA, 4 ~ 20mA or Thermocouple (J, K, T, E. R. S, B, N, C, L, M, LDIN43710) (Requires Optional External 125 Ω Resistor for current input).
Wireless 4-channel Voltage/Current Output Module
0 ~ +10VDC, -10VDC ~ +10VDC, 0 ~ +5VDC, -5VDC ~ +5VDC, 0 ~ +20mA, +4mA ~ +20mA
Wireless 4-ch Voltage Input, 2-channel Voltage Output, 2-channel Digital Input and 2-channel Digital Output Module
±10V, ±5V, ±1V, ±500mV, ±150mV, ±20mA, 0 ~ 20mA, ±20mA, 0 ~ 20mA or 4 ~ 20mA (Current Input Requires Optional External 125 Ω Resistor)
±10 VDC, ±5 VDC, 0 ~ 10 VDC or 0 ~ 5 VDC/Isolated Open Collector
Zigbee DIO (Router)
Wireless 4-channel PhotoMOS Relay Output and 4-channel Open Collector Output Module
Isolated Open Collector/ PhotoMOS Relay, Form A
Wireless 14-channel Isolated Digital Output Module
Wireless 8-ch Isolated Digital Input Module with 16-bit Counters
Wet Contact (Sink/Source)
Wireless 14-ch Isolated Digital Input Module with 16-bit Counters
Dry/ Wet Contact (Sink/Source)
Wireless 8-channel Isolated Digital Input and 8-channel Isolated Digital Output Module.
Dry/ Wet Contact (Sink/Source)
Wireless 6-channel Isolated Digital Input and 4-channel Relay Output Module.
Wet Contact (Sink/Source)
Power Relay, Form A (SPST N.O)
Wireless 4-channel Isolated Digital Input and 4-channel Isolated Digital Output Module
Zigbee Digital Pair-connection (Full Function)
ZigBee I/O Group (Pair-connection) Module with the 14-channel Isolated Digital Output
ZigBee I/O Group (Pair-connection) Module with the 14-channel Isolated Digital Input
Dry/ Wet Contact (Sink/Source)
ZigBee I/O Group (Pair-connection) Module with the 8-channel Isolated Digital Input and 8-channel Isolated Digital Output
Dry/ Wet Contact (Sink/Source)
ZigBee I/O Group (Pair-connection) Module with the 6-channel Isolated Digital Input and 4-channel Relay Output
Wet Contact (Sink/Source)
Power Relay, Form A (SPST N.O)
ZigBee Digital Pair-connection (Coordinator)
ZigBee I/O Pair-connection Module with the 8-channel Isolated Digital Input
Wet Contact (Sink/Source)
ZigBee I/O Pair-connection Module with the 8-channel Isolated Digital Input and 8-channel Digital Output
Dry/ Wet Contact (Sink/Source)
ZigBee I/O Pair-connection Module with the 4-channel Isolated Digital Input and 4-channel Relay Output
Wet Contact (Sink/Source)
Power Relay, Form A (SPST N.O)
ZigBee Sniffer
ZigBee Repeater/Bridge
ZigBee Repeater (Slave, ZigBee Router)
Zigbee Converters
RS-485/RS-232 to ZigBee Converter (Host, ZigBee Coordinator)
RS-485/RS-232 to ZigBee Converter (Slave, ZigBee Router)
Ethernet/RS-485/RS-232 to ZigBee Converter (Host, ZigBee Coordinator)
Ethernet/RS-485/RS-232 to ZigBee Converter (Slave, ZigBee Router)
