The TPM-4100/TP-4100/TP-2070/TP-3080/TP-5120/TP-6150/TP-7170
Panel Mount Monitor includes a standard TFT LCD screen with a rugged
aluminum front bezel resolution and a wide operating temperature range. The
TPM-4100/TP-4100/TP-2070/TP-3080/TP-5120/TP-6150/TP-7170 is also
guaranteed to integrate with ICP DAS PAC control systems, such as
WP-8000 series, LinPAC-8000 series and the XP-8000 series.
| Display | |
| Size | 7” |
| Resolution | 800 x 480 |
| Brightness (cd/m2) | 400 |
| Touch screen | 4-wire, analog resistive; Light Transmission: 80% |
| Contrast Ratio | 500 : 1 |
| Viewing Angle (H/V) | 140/120 |
| Backlight Life (hrs) | 20,000 |
| Touchscreen function | Combo RS-232 & USB interface |
| Input Signal | VGA (Analog RGB) |
| MMI (Man Machine Interface) | |
| OSD Control | Functions: Brightness, Contrast, Clock, Phase, Horizontal Position, Vertical Position and Sharpness |
| Power Switch | Yes |
| LED Indicators | Power, Display signal is detected |
| Power | |
| Input Range | +12 ~ 48 VDC |
| Power Consumption | 5 W |
| Mechanical | |
| Dimensions (W x L x H) | 213 mm x 148 mm x 44 mm |
| Casing | Plastic |
| Installation | Panel Mounting, VESA (75 x 75) Mounting |
| Ingress Protection | Front panel: IP65 |
| Environment | |
| Operating Temperature | -20 °C ~ +70 °C |
| Storage Temperature | -30 °C ~ +80°C |
| Ambient Relative Humidity | 10 ~ 90% RH (non-condensing) |
