I-2534

The I-2534 is one kind of CAN bus switch. There are four independent CAN channels which offer a flexible design of the start or tree network topology. This new topology could resolve the complex CAN bus application, like industrial machinery, building automation, vehicle automation, and etc. Furthermore the I-2534 integrates and exchanges data between different CAN network which has different baud rate. It helps users to extend the CAN network system. The I-2534 could increase the maximum CAN node count in a CAN network by splitting the CAN network into several subnets. In additional, the user-defined CAN baud rate and CAN filter configuration are also supported.

Applications

• Control System• Building Automation• Factory Automation• Distributed data acquisition

Features

• 4 CAN communication ports
• TJA1042 CAN transceiver
• Compatible with CAN specification 2.0A and 2.0B
• Fully compatible with the ISO 11898-2 standard
• Baud rate : 5 k, 10 k, 20 k, 33.3 k, 50 k, 62.5 k, 83.3 k, 125 k, 250 k, 500 k, 800 k, 1 M bps and user-defined
• CAN filter is configurable
• CAN bus route path is configurable
• 100 data frames buffer for each CAN channel
• Max. data flow up to 2500 fps (frames per second) for all CAN channels
• Selectable baud rate by rotary switch
• Selectable 120Ω terminator resistor by DIP switch
• LED for CAN status
• Utility tool for CAN filter, route path and user-defined baud rate configuration
• 2500 Vrms isolation on the CAN side
• 3 kV galvanic isolation between the power supply and CAN channel
• 4 kV ESD protection for each channel
• Hi-Pot, Surge, EMI and EFT testing are all pass

Network Deployment
