The RMV-511 is an intelligent multiport serial to GPRS gateway with I/O for industry M2M applications. It is designed for linking RS-485 devices to a GPRS network and remote I/O monitor. The user-friendly Axiom Driver/Utility and VxServer allow users to easily turn the built-in COM ports of the RMV-511 into standard COM ports on a PC. By virtue of its protocol independence, a small-core OS and high flexibility, the RMV-511 is able to meet the demands of every network-enabled application. In addition, the RMV-511 also supports GPRS network automatic re-connection function when the RMV-511 is broke the GPRS network by something happened. It also supports remote I/O monitor via virtual COM by Modbus RTU protocol. M2M solution will improve the service quality and reduce operating costs. Many application areas can be improved by using RMV-511.
| System | |
| CPU | 32 bit CPU |
| SRAM | 64 Kbytes |
| Flash Memory | 512 Kbytes |
| RTC | Gives time(sec, min, hour) & data, leap year compensation |
| WDT(watchdog) | Yes |
| GSM/GPRS Module | |
| Frequency Band | Quad-band: 850/900/1800/1900 MHz |
| Compliant with GSM Phase 2/2+ | Class 4 (2 W @ 850/900 MHz) |
Class 1 (1 W @ 1800/1900 MHz) |
|
| Coding Schemes | CS 1, CS 2, CS 3, CS 4 |
| Download | Max download speed 85.6 kbps |
| Upload | Max upload speed 42.8 kbps |
| GPRS multi-slot | Class 10/8 |
| Serial ports | |
| Utility port | RS-232: TxD, RxD, GND (use for device configuration and debug) |
| COM1 | RS-485: D+, D- (use for communication with other devices) |
| Baud Rate | 2400A4800A9600A19200A38400A57600 and 115200 bps |
| Digital Input | |
| Channels | 6 |
| Input Type | Sink or Source, Isolated channel with common power or ground |
| OFF Voltage Level | +1V max |
| ON Voltage Level | +3.5 ~ 30 VDC |
| Isolated Voltage | 3750 Vrms |
| Digital Output | |
| Channels | 2 |
| Output Type | Open-Collector(NPN)(100mA@30VDC) |
| Load Voltage | +30 V max |
| Load Current | 100 mA max |
| Isolated Voltage | 3750 Vrms |
| Analog Input | |
| Channels | 1 |
| Resolution | 12 bits |
| Input Range/Type | 0~20 mA |
| Power | |
| Protection | Reverse polarity protection |
| Frame Ground Protection | ESD, Surge, EFT, Hi-Pot |
| Required Supply Voltage | +10 VDC ~ +30 VDC |
| Mechanical | |
| Casing | Plastic |
| Flammability | UL 94V-0 materials |
| Dimensions (W x L x H) | 91 mm x 132 mm x 52 mm |
| Installation | DIN-Rail |
| Environmental | |
| Operating Temperature | -25 °C ~ +75 °C |
| Storage Temperature | -30 °C ~ +80 °C |
| Ambient Relative Humidity | 5 ~ 95% RH, non-condensing |
