M-7018R (high voltage protection)

$529.00
8 Channel Analog Input Data Acquisition Module. Supports Current Input Types of +/-20mA (requires optional external 125 ohm resistor), Voltage Input Types: +/-15mV, +/-50mV, +/-100mV, +/-500mV, +/-1V, +/-2.5V and Thermocouple Input Types J, K, T, E, R, S, B, N, and C. Communicable over Modbus RTU and RS-485. Supports operating temperatures between -25°C to 75°C (-13°F ~ 167°F).
Availability: IN STOCK | FASTEST DELIVERY : Monday, Oct 12 | Enter ZIP below for shipping options
Get Shipping Options
QTY
-
+
Add to Quote
Buy With One Click
Share On:
Categories: M-7000 Modbus RTU Remote Data Acquisition Modules | M-7000 Modbus RTU Remote Data Acquisition Modules
Review: Write your review
Resources:

M-7018r WireThe M-7000 series is a family of network data acquisition and control modules that support Modbus RTU. They can be remotely controlled using a set of commands called DCON protocol. With the Modbus RTU protocol, it can easily communicate with most popular SCADA/ HMI software and PLCs.


  • Indication LED Light
    • For power and communication
  • Over voltage protection:240Vrms
  • Support Modbus and DCON Protocol
  • Analog Input Channels: 8 differential
  • Type: mV, V , mA
  • Thermocouple: Type J, K, T, E, R, S, B, N, C
  • Din Rail Mount

Specifications
