FRnet Fast AI/AO Application for The ISaGRAF PAC

ICP DAS releases a new application: the ISaGRAF PAC application using the FRnet fast AI/AO new modules, FR-2024iT and FR-2017iT. ISaGRAF is the most powerful SoftLogic package on the industrial market that supports IEC 61131-3 standard PLC programming languages. FRnet is an innovative industrial field bus with features such as high-speed/long-distance transmission reliability and wire-saving FRnet control. The new FRnet I/O modules (iT models) include built-in isolation. Selecting ISaGRAF PACs with FRnet fast I/O modules provides a more stable and faster automation control system, especially for long-distance and multi-noise industrial field applications.

Introduction for the FRnet Fast AI/AO Application

1. This application explains how to read/write the status of FRnet AI (FR-2024iT) / AO (FR-2017iT) modules with the ISaGRAF PAC via the FRnet master module (I-8172W).
2. The following ISaGRAF drivers support the operation of FRnet AI/AO modules:

   ISaGRAF PAC	Version
   WP-8xx7/8xx6	1.48
   VP-25W7/23W7/25W6/23W6	1.40
   XP-8xx7-CE6/XP-8xx6-CE6	1.28

The Features of the FRnet Fast I/O

• High-speed transmission: max. 1 Mbps
• Long-distance transmission: max. 400 m
• Built-in isolation function for the new I/O models
• No extra programming required for hardware setup
• Easy to install and debug
• Easy maintenance and cost effective
