The DN-800V series are voltage input attenuator. The maximum input range is from ±80 V to +/- 600 V and can be attenuated to ±10 V. The "I" version provide 3000VDC intra-modules isolation and 3000VDC channel to channel isolation to avoid the noise interference from inputs to outputs or channel to channel. It can be used with the analog input modules such as I-7017 and I-87017 etc. to measure the high voltage.
| General | |
| Channels | 8 |
| Input Type | AC/DC Voltage |
| Input Range | +/- 10 Vpp |
| Output Range | +/- 10 Vpp |
| Accuracy | 1% of FSR |
| Channel to Channel Isolation | Yes, 3000 VDC |
| Bandwidth | 30 KHz |
| Input Impedance | > 1 MΩ |
| Intra-module Isolation, Input to Output | 3000 VDC |
| EMS Protection | |
| ESD (IEC 61000-4-2) | +/- 4 kV contact for power line, input and output channels , +/- 8 kV air for random point |
| Surge (IEC 61000-4-5) | +/- 3 kV for power liner |
| Power Input | |
| Input Range | +10 ~ +24 VDC |
| Power Consumption | 9.2 W |
| Mechanical | |
| Dimensions (W x L x H) | 122 mm x 174 mm x 33 mm |
| Installation | DIN-Rail Mounting |
| Environment | |
| Operating Temperature | -25 °C ~ +75 °C (-13°F +167°F) |
| Storage Temperature | -30 °C ~ +75 °C (-22°F ~ +176°F) |
| Humidity | 5% ~ 95% RH, Non-condensing |
