PROFIBUS (PROCESS FIELD BUS) which is anchored in the international standards IEC 61158 and IEC 61784 is an open, digital communication system with a wide range of applications, particularly in the fields of factory and process automation. The CNT-PROFI connector is used to connect a PROFIBUS node to the PROFIBUS line featuring quick-connect technology, making the stripping of bus conductors superfluous. The connector is quick to install, and has a plastic housing and integrated terminating resistors. Anyway the CNT-PROFI could link a PROFIBUS device to a PROFIBUS line easily and fast.
Cable outlet |
90° cable outlet |
Connector |
9-pin, D-Sub male connector |
Baud rate |
9.6kbps ~ 12Mbps |
Operating temperature |
-25℃ ~ 75℃ |
Storage temperature |
-30℃ ~ 80℃ |
Humidity |
10 ~ 90% RH, non-condensing |
