The TP-4100 Panel Mount Monitor adopts a standard 10.4" TFT LCD screen with rugged aluminum front bezel and supports 800 x 600 resolution, and -25 ~ 75°C operating temperature. The TPM-4100/TP-4100 is also guaranteed to work with ICP DAS PAC control system, such as WP-8000 series, XP-8000 series.
| Models | TP-4100 |
| Display | |
| Display | 10.4 |
| Resolution | 800 x 600 |
| Max. Color | 16.7 M |
| Brightness (cd/m2) | 320 |
| Contrast Ratio | 500 : 1 |
| Viewing Angle (H/V) | 140/130 |
| Backlight Life (hrs) | 50,000 |
| Touch Panel | 5-wire |
| analog resistive, RS-232 or USB1.1 (Type B) interface | |
| Input Signal | VGA (Analog RGB) |
| MMI (Man Machine Interface) | |
| OSD Control | Functions: Brightness, Contrast, Phase, Horizontal Position, Vertical Position and Sharpness |
| Power Switch | Yes |
| LED Indicators | Power, Display signal is detected |
| Power | |
| Input Range | +12 ~ 48 VDC |
| Power Consumption | 8.5 W |
| Mechanical | |
| Casing | Plastic |
| Dimensions (W x L x H) | 290 mm x 228 mm x 53 mm |
| Installation | Panel Monuting, VESA (75 75) Mounting |
| Ingress Protection | Front panel: IP65 |
| Environment | |
| Operating Temperature | -25 °C ~ +75 °C |
| Storage Temperature | -30 °C ~ +80 °C |
| Ambient Relative Humidity | 10% ~ 90% RH, non-condensing |
