The PIO-D48U/PEX-D48 is the new generation product that ICP DAS provides to meet RoHS compliance requirement and is designed as completely compatible with the PIO-D48. Users can replace the PIO-D48 by the PIO-D48U/PEX-D48 directly without software/driver modification.
The PIO-D48U supports 3.3 V/5 V PCI bus, while the PEX-D48 supports PCI Express bus. These cards provide 48 TTL digital I/O lines, and these lines are grouped into six 8-bit bi-direction ports. Every three 8-bit ports are grouped as port A (PA), port B (PB) and port C (PC) on a connector, and the port C can be split into 2 nibble-wide(4-bit) parts. All ports are configured as inputs upon power-up or reset.
The PIO-D48U/PEX-D48 also adds a Card ID switch and pull-high/ pull-low resisters for DI on board. Users can set Card ID on a board and recognize the board by the ID via software when using two or more PIO-D48U/PEX-D48 cards in one computer. The pull-high/ pull-low resisters allow the DI status to be specified when the DI channels are unconnected; the DI status will remain in high or low status other than floating.
The PIO-D48/D48U and PEX-D48 supports various OS such as Linux, DOS, Windows 98, Windows 2000, Windows NT, Windows XP 32-Bit, Vista 32-Bit and 32-bit Windows 7. It also provides the DLL and Active X control, and various language sample programs in Turbo C++, Borland c++, Microsoft C++, Visual C++, Borland Delphi, Borland C++ Builder, Visual Basic, C#.NET, Visual Basic.NET and LabVIEW to help users to quickly and easily develop their applications.
| Model Name | PIO-D48 | PIO-D48U | PEX-D48 |
| Programmable Digital I/O | |||
| Channels | 48 | ||
| Digital Input | |||
| Compatibility | 5 V/TTL | ||
| Input Voltage | Logic 0: 0.8 V max. Logic 1: 2.0 V min. |
||
| Response Speed | 1.2 kHz/MHz (Typical) | ||
| Digital Output | |||
| Compatibility | 5 V/TTL | ||
| Output Voltage | Logic 0: 0.4 V max. Logic 1: 2.4 V min. |
||
| Output Capability | Sink: 64 mA @ 0.8 V Source: 32 mA @ 2.0 V |
||
| Response Speed | 1.2 kHz/MHz (Typical) | ||
| Timer/Counter | |||
| Channels | 2(Event Timer x 1/32-bit Timer x 1) | ||
| Resolution | 16-bit | ||
| Compatibility | 5 V/TTL | ||
| Reference Clock | Internal: 4 MHz | ||
| General | |||
| Bus Type | 5 V PCI, 32-bit, 33 MHz | 3.3 V/5 V Universal PCI, 32-bit, 33 MHz | PCI Express x 1 |
| Data Bus | 8-bit | ||
| Card ID | No | Yes(4-bit) | |
| I/O Connector | Female DB37 x 1 50-pin box header x 1 |
||
| Dimensions (L x W x D) | 156 mm x 105 mm x 22 mm | ||
| Power Consumption | 900 mA @ +5 V | ||
| Operating Temperature | 0 ~ 60 °C | ||
| Storage Temperature | -20 ~ 70 °C | ||
| Humidity | 5 ~ 85% RH, non-condensing | ||
