The I-87017RW is an analog input module with an extremely high-quality protection mechanism where the overvoltage protection can be as high as 240 Vrms. The input type can be set to either voltage or current. The I-87017RW is an upgraded version of I-87017W, with the only differences being that the I-87017RW is more suitable for critically harsh environment. The sampling rate for the I-87017RW is can be adjusted to either fast mode or normal mode depending on individual requirements. The I-87017RW also provides 4 kV ESD protection as well as 3000 VDC intra-module isolation.
• 8-channel Analog Input
• Voltage or Current Input
• +/-35 VDC Overvoltage Protection
• Adjustable Sampling Rate
| CPU Module | |
|---|---|
| Watchdog Timer | Yes, Module (1.6 Seconds), Communication (Programmable) |
| Isolation | |
|---|---|
| Intra-module Isolation | 3000 VDC |
| EMS Protection | |
|---|---|
| ESD (IEC 61000-4-2) | ± 4 kV Contact for Each Terminal ±8 kV Air for Random Point |
| LED Indicators | |
|---|---|
| Status | 1 x Power and Communication 16 x I/O |
| Analog Input | |
|---|---|
| Channels | 8 |
| Type | Voltage Current |
| Range | ±10 VDC, ±5 VDC, ±1 VDC ±500 mV, ±150 mV 0 ~ +20 mA, +4 ~ +20 mA, -20 mA ~ +20 mA (Requires Optional External 125 Resistor) |
| Resolution | 16-bit |
| Accuracy | Normal Mode: ±0.1% of FSR Fast Mode: ±0.5% of FSR |
| Sampling Rate | Normal Mode: 10 Hz Fast Mode: 50 Hz |
| Bandwidth | Normal Mode: 15.7 Hz Fast Mode: 78.7 Hz |
| Input Impedance | 20 M |
| Common Mode Rejection | 86 dB |
| Normal Mode Rejection | 100 dB |
| Overvoltage Protection | -35 VDC ~ +35 VDC |
| Zero Drift | ±20 V/°C |
| Span Drift | ±25 ppm/°C |
| COM Ports | |
|---|---|
| Ports | 1 x RS-485 |
| Baud Rate | 1200 to 115200 bps |
| Data Format | N, 8, 1 |
| Protocol | DCON |
| Power | |
|---|---|
| Consumption | 1.3 W Max. |
| Mechanical | |
|---|---|
| Dimensions (mm) | 30 x 102 x 115 (W x L x H) |
| Environment | |
|---|---|
| Operating Temperature | -25 ~ +75 °C |
| Storage Temperature | -40 ~ +85 °C |
| Humidity | 10 ~ 95% RH, Non-condensing |
