The I-8017HCW is a high performance analog input module. Up to 16-channel single-ended or 8-channel differential inputs can be connected to one module. It features 14-bit resolution, 100Ks/s sampling rates. It provides isolation protection of 2500 VDC.
| Analog Input | |
| Input Channels | 16-ch Single-ended/8-ch Differential |
| Input Range | +/- 10 V, +/- 5 V, +/- 2.5 V, +/- 1.25 V -20 mA ~ +20 mA (Jumper Select) |
| Resolution | 14-bit |
| Sample Rate | Single Channel Polling Mode :100K S/s Single Channel Interrupt Mode: 50K S/s 8 channel Scan Mode : 16 K S/s |
| Accuracy | ±0.1% of FSR |
| Zero drift | ± 0.1uV/°C |
| Span drift | ± 10ppm/°C |
| ESD Protection | 4KV |
| Input Impedance | 20K, 200K, 20M(Jumper Select) |
| Input Bandwidth | 100 KHz |
| Intra-module Isolation, Field to Logic | 2500 VDC |
| LED Display | |
| 1 LED as Power Indicator/16 LED as Status Indicator | |
| Power | |
| Power Consumption | 2W Max |
| Environment | |
| Operating Temperature | -25 ~ 75 °C |
| Storage Temperature | -30 ~ 75 °C |
| Humidity | 5 ~ 95%, Non-condensing |
| Dimensions | |
| 30 mm x 102 mm x 115 mm (W x L x H) | |
