I-7513

The I-7513 is an industrial isolated RS-485 hub with three-way active star wiring. It can be used to expand RS-485 network by splitting one RS-485 network into three, as well as increase the maximum distance of a RS-485 up to 4000 feet (1.2km) and increase the maximum number of nodes. The unit has 3 independent RS-485 output channels - each of the channel comes with their own driver to transmit signals. The I-7513 can work as both a hub and repeater. Each output channel can be connected to another hub. It features 3000 VDC isolation protection and ESD protection, which helps effectively protect your system. The I-7513 RS-485 hub ensures fast data transmission - it supports up to 115.2k baud rate and features data auto-switching and a built-in self-tuner. It is an easy-to-use plug-and-play RS-485 hub that doesn't require manual settings, software drivers or flow control. It can be easily mounted on a din rail.

• Industrial Isolated RS-485 hub
• Expands RS-485 Network to up to 4000 Feet (1.2km) by Splitting One RS-485 Network into Three
• Each channel on the hub has its own RS-485 driver.
• Better Protection: 3000V DC Isolation on Each of the Three RS-485 Channels
• Input (Master): 1 RS-485 Channel: Data+, Data-
• Output (Slave): 3 RS-485 Channels: Data+, Data-
• Fast Speed: Built-in Self Tuner, Supports Speed up to 115200 bps
• Auto Switching Baud Rate, Plug and Play, Easy-to-use
• No Software or Flow Control Required.
• No DIP Switch or Jumper Settings Needed.
• Easy to install: Din rail mount and plug-in screw terminal block connector
• External Power Input: +10V DC ~ +30V DC
• Low Power Consumption: 2.2W (Maximum)
• Operating temperature: -13F to 167F (-25ºC to 75ºC).
• Surface Mount Technology manufactured to RoHS and ISO-9001 standards.
• Free technical support and 1-year Free Warrranty. 100% Customer Satisfaction Guaranteed.
