The maximum data throughput for all CAN channels combined on the I-2534 and I-5534-M modules is up to 2,500 frames per second (FPS). This total throughput applies across all active CAN channels operating simultaneously.
Actual achievable frame rates depend on CAN baud rate, bus loading, message size, arbitration priority, and network topology. Proper termination, cable quality, and node count also impact real-world performance.
These modules are commonly used in applications such as machine control, vehicle communication networks, embedded automation systems, protocol gateways, and industrial CAN data acquisition.
