| Safety | |
| Standard | UL60950-1, CSA C22.2, TUV EN60950-1, BSMI CNS14336 approved |
| EMC | |
| Standard | Compliance to EN55022 class B, FCC PART 15 / CISPR22 class B, CNS13438 class B |
| Input | |
| Voltage Range | 90-264VAC |
| Frequency Range | 47-63Hz |
| Ac Current (Typ.) | 0.7A/100VAC |
| Inrush Current (Typ.) | 40A/230VAC |
| Leakage Current | 0.75 mA/240 VAC |
| Output | |
| Ripple & Noise (Max.) | 180mVp-p |
| Setup, Rise Time | 600ms, 50ms |
| Hold Up Time (Typ.) | 16ms at full load |
| DC Voltage | 48VDC |
| Rated Power | 25W |
| Rated Current | 0.52A |
| Efficiency | 82% typical |
| Protection | |
| Over Voltage | Yes (clamp by Zener diode). |
| Mechanical | |
| Casing | Plastic |
| Dimensions (mm) | (74 * 109 * 52)mm |
| Installation | DIN-Rail Mounting |
| Environmental | |
| Temperature Coefficient | ±0.04%/°C (0~50°C) |
| Operating Temperature | 0 ~ +50°C |
| Storage Temperature | -20 ~ +85°C |
| Humidity | 20% ~ 90% RH, Non-condensing |
